Product Description

รายละเอียดคุณลักษณะจำเพาะ

Dlsb-5/10 Recirculating Water Chiller รุ่น DLSB 5L-10

รายละเอียดคุณลักษณะจำเพาะ

The application of Low temperature circulating pump:DLSB low temperature pump adopts mechanical refrigeration low temperature circulating equipment and provide constant current and constant voltage circulating liquid to meet the requirement of the decreasing instrument (electric microscope, electricity probe,x-ray machine,laser reactor and accelerator) so as to guarantee the required working temperature
The machine is an essential to make sure the normal working condition for the device adopting constant current and constant pressure to cool in the condition of lacking water place ,bad quality of water and higher temperature.It can provide low temperature liquid to have multiple function of chemical reaction and medicine storage collocated with rotary evaporator,vacuum drying oven,circulating water multiple pump,magnetic force stirrer.It is especially used for different kinds of chemical biology ,physical lab which needed low temperature.It is the essential lab instrument for pharmacy,food industry,metallurgical industry and college scientific research.



Model name DLSB 5L-10°C
Tank volume (L) 5
lowest no-load temperature(°C) -15
Using temperature range (°C) room temperature—-15
best temperature range(°C) 5~25
Environmental relative humidity (%) ≤70
Working power supply (V/HZ) single phase220-50
temperature display mode liquid crystal
temperature stability(°C) ±2
Sensor index Pt100
Instrument adjusting range (°C) ±150
set way Arbitrary adjustment of Settings in the range of use
safety protection delay,leakage,over current,overheat
output refrigerating capacity (W) 10°C 620
0°C 460
-10°C 280
-20°C -
Total machine power (W) 420
Machine current (A) 2.1
refrigerant 134A
Circulating pump Power(w) 100
Flow rate(L/min) 20
Lift(M) 4~6
external loop interface Threaded joint 12 inches
opening size(mm) 160×160
tank shape square
Internal diameter and height of liquid storage tank (mm) 170×170×170
Overall appearance size (mm) 400×260×530
Machine weight (kg) 28
fuse 5A
matching parts one set

Brand

LANPHAN
